What is freight density?
Freight density is the weight of a shipment per cubic foot of space it occupies, expressed in pounds per cubic foot. It is the single biggest input to NMFC freight class and a primary driver of LTL shipping cost. For shippers of low-density products, density can triple the cost of a shipment. Per-pallet pricing eliminates density from the equation entirely.
Per-pallet pricing · No density surcharges · No reclass risk · 2,000+ shippers
Live all-inclusive rates
How to calculate freight density
Freight density is weight divided by volume, expressed in pounds per cubic foot. The formula is straightforward: density = weight (lb) divided by total cubic feet.
To get cubic feet from inches, multiply length x width x height and divide by 1,728 (12 x 12 x 12).
Worked example. You have a pallet measuring 48 in long by 40 in wide by 48 in tall, weighing 1,000 lb. Volume in cubic inches is 48 x 40 x 48 = 92,160. Divide by 1,728 to get 53.3 cubic feet.
Divide 1,000 lb by 53.3 cubic feet and you get 18.8 lb/ft³. That density lands in NMFC class 70, which is the cheapest end of the class spectrum for most commodities.
Measurement rules matter. Include the pallet dimensions, not just the product footprint.
If freight overhangs the pallet edge even by an inch, use the overhanging dimensions for the density calculation because that is what the carrier's cubing equipment measures. Round up to the nearest inch on each dimension.
Many carriers cube inbound freight at their break-bulk terminals using laser dimensioners; if their measurement disagrees with yours, the carrier's number wins and a reclassification charge follows. Measure carefully before you book.
The Warp density calculator at /tools/density-calculator runs this calculation in the browser. Enter length, width, height, weight, and pallet count, and it returns density in PCF plus the likely NMFC class range.
Use it to verify your density before booking any traditional LTL shipment. If you book through Warp, the density output carries through to your quote via a prefilled link.
Density and NMFC freight class
The National Motor Freight Classification (NMFC) system groups commodities into 18 classes from 50 to 500.
Density is one of four NMFC inputs (the others are handling, stowability, and liability) but in practice density drives the majority of class assignments for standard palletized freight.
Here is how density maps to class for density-based commodities (NMFC items that rate by density alone). Class 50: 50 lb/ft³ and above. Class 55: 35 to 50 lb/ft³. Class 60: 30 to 35 lb/ft³. Class 65: 22.5 to 30 lb/ft³. Class 70: 15 to 22.5 lb/ft³.
Class 77.5: 13.5 to 15 lb/ft³. Class 85: 12 to 13.5 lb/ft³. Class 92.5: 10.5 to 12 lb/ft³. Class 100: 9 to 10.5 lb/ft³. Class 110: 8 to 9 lb/ft³. Class 125: 7 to 8 lb/ft³. Class 150: 6 to 7 lb/ft³. Class 175: 5 to 6 lb/ft³. Class 200: 4 to 5 lb/ft³.
Class 250: 3 to 4 lb/ft³. Class 300: 2 to 3 lb/ft³. Class 400: 1 to 2 lb/ft³. Class 500: below 1 lb/ft³.
Not every commodity rates purely on density. Some NMFC items have fixed classes regardless of density (think hazmat, fragile electronics, high-value freight). Others have sub-codes that layer handling or packaging requirements on top of density.
But for the bulk of standard palletized freight moving through the U.S. LTL network, the density table above is the practical guide.
The crossover points matter. A shipment at 15.1 lb/ft³ is class 70, but a shipment at 14.9 lb/ft³ is class 77.5. That 0.2 lb/ft³ swing can change your rate by 5 to 10 percent on the same lane.
Shippers who sit near class boundaries should measure dimensions obsessively because small errors produce big invoice changes.
Why density drives LTL pricing
LTL trailers are space-constrained, not weight-constrained, on the majority of lanes. A 53 foot dry van holds about 26 pallet positions and up to 44,000 lb of payload.
On most freight mixes, the trailer fills with pallets before it hits the weight limit. The bottleneck is cubic feet, not pounds.
This shapes carrier pricing. A carrier who loads 26 pallets of dense freight (say 1,500 lb per pallet at 20 lb/ft³) moves 39,000 lb of revenue-generating freight per trailer.
That same carrier loading 26 pallets of low-density freight (say 200 lb per pallet at 2 lb/ft³) moves only 5,200 lb of revenue freight in the same trailer.
The revenue per mile on the dense load is far higher than on the light load, even though both loads use the same driver, truck, fuel, and terminal labor.
To balance this, carriers price low-density freight at much higher rates per hundredweight. That is the economic reason density drives class and class drives cost.
The carrier is being compensated for the space the freight occupies, not just the weight it carries.
The same economics create an opportunity. If you ship low-density product and can find ways to increase density (denser packaging, smaller void spaces, stacking product taller), you move into a cheaper class on every shipment and save on every lane.
A 20 percent density gain often pays back in weeks through reduced LTL rates.
There is a cleaner solution for shippers who cannot change their product density: switch to per-pallet pricing. Warp prices by pallet count regardless of density.
A pallet of pillows (3 lb/ft³, class 300 in traditional LTL) ships at the same pallet rate as a pallet of canned goods (25 lb/ft³, class 55). The density trap disappears.
Freight density vs dimensional (DIM) weight
Freight density and dimensional weight are related but used in different modes. Density is the raw physical measurement: pounds per cubic foot.
DIM weight is a billing formula used by parcel carriers (FedEx, UPS, USPS) to charge for lightweight packages that take up trailer space disproportionate to their actual weight.
DIM weight formula: DIM weight (lb) = (L x W x H in inches) / divisor. The divisor is typically 139 for domestic parcel on FedEx and UPS (the current industry standard) or 166 for some legacy and international rates.
Carriers bill the greater of actual weight or DIM weight.
Example: a 20 x 20 x 20 inch parcel weighing 5 lb has a DIM weight of 8,000 / 139 = 57.6 lb. The carrier bills at 58 lb even though the actual weight is 5 lb.
This matters for lightweight bulky parcel freight (pillows, empty containers, foam products) where DIM weight can be 10x or more the actual weight.
LTL does not use DIM weight. LTL uses density directly to determine freight class, and class determines the rate. The underlying economics are similar (carriers are compensated for space, not just weight) but the mechanism is different.
If you are moving freight across both parcel and LTL modes, you need to understand both: DIM weight for parcel billing, density for LTL classification.
Warp's LTL model sidesteps both: per-pallet pricing covers the space without requiring density math or NMFC lookup. Warp's parcel-alternative (cargo van and box truck) prices by load or by pallet count, not by DIM weight.
Shippers who move freight that gets penalized by DIM weight on parcel carriers often find cargo van or LTL per-pallet pricing much cheaper on the same lane.
How to reduce freight class by increasing density
For shippers of low-density products in the traditional LTL system, increasing density is one of the highest-leverage cost reduction tactics available.
A small packaging change can drop your freight class and save 10 to 30 percent on every shipment for as long as you ship that product.
Tactics that work. Stack product taller within the pallet footprint instead of wider. A double-stacked pallet at 72 inches tall has more density than two single pallets at 36 inches. Eliminate void fill.
Cardboard spacers, air pillows, and foam take up cubic feet without adding weight, pushing density down. Use denser internal packaging. Shrink-wrap individual units tighter. Nest product where possible.
Ship partially disassembled goods if the unboxed parts stack denser than the assembled product.
Do the math before committing. Take your current shipment weight and dimensions, calculate current density, identify your class, and look up the rate per hundredweight on your top 3 lanes.
Then model the denser version: same weight, smaller cubic feet, new density, new class, new rate. Multiply the savings by annual shipment count to get annual impact.
If the payback exceeds the packaging change cost within 6 months, the change is worth making.
The ceiling: some products cannot be made denser without compromising the product itself. Furniture, mattresses, styrofoam, and large lightweight consumer goods are inherently low density.
For those shippers, the real cost lever is not packaging redesign but switching to a pricing model that does not penalize density. Per-pallet pricing is the structural answer when density-based pricing is working against your product mix.
Typical freight density by commodity
Rough density ranges for common LTL commodities, sorted by density. Use these as starting points when estimating class for a new product.
High density (class 50 to 65). Steel products, hardware, bolts, and fittings: 30 to 50 lb/ft³. Industrial machinery and parts: 25 to 40 lb/ft³. Canned goods, bottled beverages, and packaged food: 20 to 30 lb/ft³. Automotive parts: 15 to 30 lb/ft³.
Bricks, tile, and dense building materials: 40 lb/ft³ and above.
Medium density (class 70 to 100). Household appliances (washers, dryers, refrigerators): 12 to 18 lb/ft³. Boxed consumer electronics: 10 to 15 lb/ft³. Printed books and paper products: 15 to 30 lb/ft³.
Packaged apparel and textiles (folded and boxed): 10 to 18 lb/ft³. Boxed housewares and kitchenware: 10 to 14 lb/ft³.
Low density (class 125 to 250). Boxed sofas and upholstered furniture: 6 to 10 lb/ft³. Mattresses (boxed): 4 to 8 lb/ft³. Boxed bicycles and sporting goods: 5 to 9 lb/ft³. Pet beds, pillows, and bedding: 3 to 6 lb/ft³.
Very low density (class 300+). Styrofoam, foam insulation, and packaging foam: 1 to 2 lb/ft³. Empty plastic containers and bins: 2 to 4 lb/ft³. Balloons, ping pong balls, and similar ultra-light goods: below 1 lb/ft³.
These are directional ranges, not NMFC commitments. Your actual class depends on the specific NMFC item description, handling requirements, and any sub-codes. Verify via the NMFC Lookup tool before booking.
The reclassification trap in traditional LTL
Reclassification is the most common source of invoice surprise in traditional LTL. You book a shipment at class 70, the carrier cubes it at their terminal, decides the density is actually 12 lb/ft³, and rebills at class 85.
The difference shows up on the invoice 2 weeks after delivery. Reclassification charges can add 20 to 50 percent to a shipment cost.
How it happens. The shipper estimates dimensions quickly at booking. The carrier pickup driver eyeballs the freight and records what the shipper provided.
At the terminal or break-bulk, the freight passes through a laser dimensioner that measures length, width, and height precisely. The system recalculates density, assigns the correct class, and flags the discrepancy.
A reclassification notice generates on the next invoice cycle.
Why shippers lose these disputes. The carrier's cubing equipment is calibrated and timestamped. The shipper's measurement is usually from a tape measure with no documentation. In a dispute, the carrier's data wins.
The shipper pays the reclass charge or spends hours in a tariff dispute that rarely succeeds.
Prevention tactics in traditional LTL. Measure to the outer edges of any overhang, not just the pallet footprint. Round dimensions up to the nearest inch. Photograph the freight at pickup with a tape measure in frame.
Use a scale that prints a weight ticket, not a shipping scale you eyeball. Keep records for 90 days. None of this guarantees you win a reclass dispute, but it improves your odds materially.
Or switch to per-pallet pricing. Warp's per-pallet rate is locked when you book. No cubing at the cross dock. No NMFC recalculation. No reclass charges. The total cost is known before the truck arrives, and it does not change after.
This is a structural advantage of the cross dock model: because Warp controls routing and handling, pricing can be simpler and more stable than the legacy class-based system.
Why per-pallet pricing eliminates density from the equation
Per-pallet pricing is exactly what it sounds like: you pay a flat rate per pallet regardless of density.
A pallet is a pallet, whether it holds 200 lb of pillows at 3 lb/ft³ or 2,000 lb of canned goods at 25 lb/ft³ (within standard pallet weight limits). The rate is set by pallet count, lane, and standard pallet dimensions, not by density class.
This is a structural advantage for shippers with variable-density product mixes. A retailer shipping mixed SKU pallets where every pallet contains a different product blend gets consistent pricing across the full mix.
There is no "density arbitrage" where some products cross subsidize others and some get penalized.
It is an especially large advantage for low-density shippers. A shipper of boxed mattresses (class 175 to 250 in traditional LTL) pays 3 to 5 times the per-hundredweight rate of a class 70 shipper on the same lane.
Switching to per-pallet pricing flattens that differential. The mattress shipper pays the same per-pallet rate as the canned goods shipper on the same lane. That is often a 40 to 60 percent cost reduction on low-density freight.
The economics work for Warp because the cross dock model processes pallets as the unit of throughput. Cross dock facilities sort, stage, and move pallets, not classes.
The operational system scales with pallet count, not NMFC lookup complexity, so Warp can price the way it operates without reintroducing class-based complexity at the billing layer.
The shipper outcome: predictable cost, no reclass risk, no fuel surcharges stacked on top, no accessorial fees layered in. The rate quoted is the rate invoiced.
For shippers whose freight falls in classes 85 and above, per-pallet pricing typically saves 15 to 35 percent versus comparable terminal LTL carriers on the same lane, with the gap widening as freight class increases.
The lower your freight density, the more per-pallet pricing saves.
Frequently asked questions
What is freight density?
Freight density is the weight of a shipment per cubic foot of space it occupies, expressed in pounds per cubic foot (PCF or lb/ft³). You calculate it by dividing total shipment weight by total cubic feet.
A 48x40x48 inch pallet weighing 1,000 pounds has a density of roughly 18.75 lb/ft³ (class 70). Density is the single biggest input to NMFC freight class and a primary driver of LTL shipping cost.
How do I calculate freight density?
Multiply length, width, and height in inches, divide by 1,728 to convert to cubic feet, then divide total weight in pounds by cubic feet. Formula: density (lb/ft³) = weight / ((L x W x H) / 1728).
Example: a 48 in x 40 in x 48 in pallet at 1,000 lb = 92,160 in³ = 53.3 ft³ = 18.8 lb/ft³. Include pallet dimensions plus any overhang in your measurements, not just the product footprint.
What is a good freight density for LTL?
15 lb/ft³ and above is a "good" density for LTL because it lands in class 70 or below, which is the cheapest end of the NMFC range. Above 30 lb/ft³ drops you into class 50, the lowest-cost class.
Below 6 lb/ft³ pushes you into classes 175 and higher, where per-hundredweight rates can be 3 to 5 times more than class 70 on the same lane.
How does freight density affect LTL shipping cost?
Traditional LTL carriers price using freight class, and density is the dominant input to class. Higher density means lower class means lower rate per hundredweight.
A class 70 shipment might rate at $15 per CWT while a class 250 shipment rates at $45 per CWT on the same lane. Density-driven class can change cost by 2 to 3x on identical lanes. Per-pallet pricing (Warp) eliminates class from the equation entirely.
What is the difference between freight density and DIM weight?
Freight density is the raw physical measurement (weight per cubic foot). DIM weight is a billing formula parcel carriers derive from dimensions when a package is lighter than its footprint suggests.
Parcel DIM weight = (L x W x H) / divisor, where divisor is typically 139 (FedEx/UPS standard) or 166 (legacy). LTL uses density to set class directly; parcel uses DIM weight to bill the greater of actual vs dimensional weight.
Can I change my freight class by changing density?
Yes. Because density is the primary driver of NMFC class, any packaging change that increases density can drop you to a cheaper class.
Common tactics: stack product taller within the pallet footprint instead of wider, use denser internal packaging, eliminate void fill, ship components disassembled. Even a small density gain can move you across a class boundary.
A shift from 11 lb/ft³ to 13 lb/ft³ can drop a class 100 shipment to class 85.
Why is my carrier charging more than quoted?
The most common cause is reclassification. Traditional LTL carriers inspect freight at pickup or at a terminal and reassign class if their density reading disagrees with what the shipper booked.
Reclassification charges can add 20 to 50 percent to a shipment, and the shipper only finds out on the invoice.
The fix: weigh and measure accurately before booking, use accurate NMFC codes, or use a carrier like Warp that prices per pallet and eliminates reclassification risk entirely.
Is density-based pricing better than per-pallet pricing?
For shippers with consistently dense freight on high-density lanes, traditional density-based pricing can be competitive.
For everyone else, per-pallet pricing is more predictable, eliminates reclassification risk, and removes the complexity of NMFC lookups.
Warp's per-pallet model covers pickup, cross dock handling, line haul, and delivery in one price with no fuel surcharges and no accessorials. The exact cost is known before the truck arrives, regardless of density.
